Fixture Design

Through our metrology workshops at the very beginning of your new project, Synchron Machine Tools design team will work with you and our metrology Engineers, to develop initial concepts and single station prototypes along with extensive and detailed project schedules. This process ensures a fast design and development cycle and an optimised final Inspection fixture solution.
The Metrology Fixture can range from single station to large repeat multi-station solutions.
Our Fixtures are designed to reduce operator interaction and to allow the maximum number of measurements to be taken with the minimum number of setups. In most cases we can develop a single fixture that will allow all dimensions to be taken on any component.
We develop the concept design into final high cavitation multi-station fixtures with full 2D technical drawing and 3D models for client approval and manufacture.
